Central Kowloon Route
– Kai Tak West (CKR-KTW; Contract No. HY/2014/07) (hereafter called “the
Project”) covers part of the construction of the Central Kowloon Route (CKR).
The Project comprises
the follow works:
·
50x30m access shaft with noise enclosure
at Ma Tau Kok (MTK);
·
100m long cut-and-cover (C&C) tunnel
at MTK;
·
Demolition and re-provisioning of MTK
Public Pier;
·
160m long underwater tunnel (UWT) (Stage
1);
·
210m long UWT (Stage 2);
·
60m long C&C tunnel at Kai Tak;
·
130m long depressed road and 200m long
underpass at Kai Tak;
·
390m long underground tunnel ventilation
adit at Kai Tak;
·
Seawall demolition and construction of new
landing steps; and
·
Barging Point enclosure and conveyor
system.
The EM&A programme commenced on 4 April 2018.The impact EM&A for the Project includes
air quality and noise monitoring.
This is the first
monthly EM&A Report presenting the EM&A works carried out during the
period between 4 and 30 April 2018. As informed by the Contractor, major
activities in the reporting period were:
|
Locations
|
Site Activities
|
|
Kai
Tak
|
·
Pipe piling
·
Sheet piling
·
Hoarding erection
·
U-channel and drainage works
·
Construction of site offices
|
|
Ma
Tau Kok
|
·
Site investigation
·
Site clearance
·
Tree felling
·
Temporary Traffic Management
implementation
·
Alternation and temporary reinstatement
of road pavements for Temporary Traffic Arranagement stages
·
Installation of monitoring instrument
|
Breaches
of Action and Limit Levels for Air Quality
All 24-hour TSP result was below the Action and Limit Levels at all
monitoring locations in the reporting month.
All 1-hour TSP result was below the Action and Limit Levels at all
monitoring locations in the reporting month.
Breaches
of Action and Limit Levels for Noise
Regular Noise Monitoring
No Action Level exceedance was recorded since no noise related
complaint was received in the reporting month.
No
exceedance of Limit Level of noise was recorded in the reporting month.
Complaint,
Notification of Summons and Successful Prosecution
No environmental related complaint, notification of summons and
successful prosecution were received in the reporting month.
Reporting
Changes
There was no
reporting change in the reporting month.
Future
Key Issues
Key issues to be
considered in the next three months included:
|
Locations
|
Site Activities
|
|
Kai
Tak
|
·
Pipe piling
·
Sheet piling
·
Hoarding erection
·
U-channel and drainage works
·
Construction of site offices
|
|
Ma
Tau Kok
|
·
Site investigation
·
Site clearance
·
Tree felling
·
Temporary Traffic Management
implementation
·
Alternation and temporary reinstatement
of road pavements for Temporary Traffic Arrangement stages
·
Installation of monitoring instrument
·
Hoarding erection
·
Existing bus shelter removal
·
Provision of temporary bus shelters
·
Demolition of existing vehicular ramp and
booth structure
|
Potential environmental impacts arising
from the above construction activities are mainly associated with construction dust, construction noise, water pollution control,
and waste management.
Gammon
Construction Limited was commissioned by the Highways Department as the Civil Contractor
for Works Contract HY/2014/07. AECOM Asia Company Limited (AECOM) was appointed
by Gammon Construction Limited as the Environmental Team (ET) to undertake the
Environmental Monitoring and Audit (EM&A) programme during construction
phase of the Project.
1.1.1
This is the first monthly EM&A Report which
summaries the impact monitoring results and audit findings for the Project
during the reporting period between 4 and 30 April 2018.
1.2.1
This monthly EM&A Report is organized as follows:
· Section 1: Introduction
· Section 2: Project Information
· Section 3: Environmental Monitoring Requirement
· Section 4: Implementation Status of Environmental Mitigation Measures
· Section 5: Monitoring Results
· Section 6: Environmental Site Inspection and Audit
· Section 7: Environmental Non-conformance
· Section 8: Future Key Issues
· Section 9: Conclusions and Recommendations
2.1.1
CKR is a dual 3-lane trunk road across
central Kowloon linking the West Kowloon in the west and the Kai Tak
Development (KTD) in the east. The CKR will be about 4.7 km long with an
underground tunnel section of about 3.9 km long, in particular, there will be
an underwater tunnel of about 370 m long in Kowloon Bay to the north of the To
Kwa Wan Typhoon Shelter. It will connect the West Kowloon Highway at Yau Ma Tei
Interchange with the road network at Kowloon Bay and the future Trunk Road T2
at KTD which will connect to the future Tseung Kwan O – Lam Tin Tunnel
(TKO-LTT) and Cross Bay Link (CBL). CKR, Trunk Road T2 and TKO-LTT will form a
strategic highway link, namely Route 6, connecting West Kowloon and Tseung Kwan
O. In addition, 3 ventilation buildings, which will be located in Ya Ma Tei, Ho
Man Tin and ex-Kai Tak airport area, are proposed to ensure acceptable air
quality within the tunnel.
2.1.2
The Environmental Impact Assessment (EIA) Report for Central Kowloon Route (Register No.: AEIAR-171/2013)
was approved on 11 July 2013 under the Environmental Impact Assessment
Ordinance (EIAO). Following the approval of the EIA Report, an Environmental
Permit (EP) for CKR was granted on 9 August 2013 (EP No.: EP- 457/2013) for the
construction and operation. Variation of EP (VEP) was subsequently applied
and the latest EP (EP No. EP-457/2013/C) was issued by the Director of
Environmental Protection (DEP) on 16 January 2017. Further Environmental Permit (EP No.
FEP-01/457/2013/C) for CKR – Kai Tak West was issued on 28 February 2018.
2.1.3
The
construction of the CKR had been divided into different sections. This Work
Contract HY/2014/07 – Kai Tak West (KTW) (“The Project”) will include a road which is a trunk road, including new roads, and major
extensions or improvements to existing roads; a road fully enclosed by decking
above and by structure on the sides for more than 100 m; and reclamation works
(including associated dredging works) more than 1 ha in size and a boundary of
which is less than 100 m from an existing residential area.
2.1.4
The site layout plan of the Project is
shown in Figure 1.1.
2.2.1
The major construction activities under
this Project include:
(a) construction of approximately 160m long cut-and-cover tunnel and
370m long underwater tunnel between the tunnel section at Ma Tau Kok and the
depressed road of the CKR within Kai Tak Development;
(b) reconstruction of the seawall at Ma Tau Kok public pier, and the
sloping seawall at the Former Kai Tak Airport Runway;
(c) construction of approximately 125m long depressed road and 200m
long underpass of the CKR within Kai Tak Development;
(d) construction of approximately 360m long underground tunnel
ventilation adit of the CKR;
(e) reconstruction of Kowloon City Ferry Pier Public Transport
Interchange; and
(f) other associated works.
2.3.1
The major construction activities
undertaken in the reporting month are summarized below:
|
Locations
|
Site
Activities
|
|
Kai Tak
|
·
Pipe piling
·
Sheet piling
·
Hoarding erection
·
U-channel and drainage works
·
Construction of site offices
|
|
Ma Tau Kok
|
·
Site investigation
·
Site clearance
·
Tree felling
·
Temporary Traffic Management
implementation
·
Alternation and temporary reinstatement
of road pavements for Temporary Traffic arrangement stages
·
Installation of monitoring instrument
|
2.3.2
The
construction programme is presented in Appendix A.
2.4.1
The project organization structure is shown in Appendix B. The key personnel contact names and numbers
for the Project are summarized in Table
2.1.
Table 2.1 Contact Information of Key Personnel
|
Party
|
Role
|
Position
|
Name
|
Telephone
|
Fax
|
|
Arup-Mott
MacDonald Joint Venture
|
Residential
Engineer (ER)
|
Engineer’s Representative
|
Mr. Jeffrey
Lau
|
2268 3640
|
2268 3954
|
|
ERM
|
Independent
Environmental Checker (IEC)
|
Independent
Environmental Checker
|
Ms. Mandy To
|
2271 3313
|
2723 5660
|
|
Gammon
|
Contractor
|
Contracts
Manager
|
Mr. Alan Yan
|
2516 8823
|
2516 6260
|
|
Environmental Manager
|
Mr. Brian Kam
|
9456 9541
|
2516 6260
|
|
Environmental
Officer
|
Ms. Phoebe Ng
|
9869 1105
|
|
AECOM
|
Contractor’s
Environmental Team (ET)
|
ET Leader
|
Mr. YT Tang
|
3922 9392
|
2317 7609
|
2.5.1 Relevant environmental licenses, permits and/or
notifications on environmental protection for this Project and valid in the
reporting month are summarized in Table 2.2.
Table 2.2 Status of Environmental Licenses, Notifications and Permits
|
Permit / License No. / Notification/
Reference No.
|
Valid Period
|
Status
|
Remarks
|
|
From
|
To
|
|
Further
Environmental Permit
|
|
FEP-01/457/2013/C
|
28 Feb 2018
|
End of Project
|
Valid
|
--
|
|
Wastewater
Discharge License
|
|
WT00030290-2018
|
22 Mar 2018
|
31 May 2023
|
Valid
|
Ma Tau Kok
|
|
Chemical Waste Producer Registration
|
|
5118-247-G2347-47
|
30 Jan 2018
|
End of Project
|
Valid
|
--
|
|
5118-247-G2347-48
|
30 Jan 2018
|
End of Project
|
Valid
|
--
|
|
Billing
Account for Construction Waste Disposal
|
|
7029909
|
22 Jan 2018
|
End of Project
|
Account Active
|
--
|
|
Notification
Under Air Pollution Control (Construction Dust) Regulation
|
|
429442
|
5 Jan 2018
|
5 Jul 2025
|
Notified
|
--
|
Monitoring
Requirements
3.1.1 In accordance with the approved EM&A Manual, measurement of 24-hour
and 1-hour Total Suspended Particulates (TSP) level at the designated air
quality monitoring station is required. Impact 24-hour TSP monitoring should
be carried out for at least once every 6 days, and
1-hour TSP monitoring should be done at least 3 times every 6 days while the
highest dust impact is expected. The Action and Limit Levels of the air quality
monitoring is provided in Appendix D.
Monitoring Equipment
3.1.2 24-hour TSP air
quality monitoring was performed using High Volume Sampler (HVS) located at the
designated monitoring station. The HVS meets all the requirements of the
EM&A Manual.
3.1.3 A portable direct
reading dust meter was used to carry out the 1-hour TSP monitoring.
3.1.4 Brand and model
of the equipment is given in Table 3.1.
Table 3.1 Air Quality Monitoring
Equipment
Monitoring Locations
3.1.5
The monitoring station for construction dust monitoring
pertinent to the Project has been identified based on the approved EM&A
Manual for the Project. The location of
the construction dust monitoring station is summarized in Table 3.2 and
shown in Figure 3.1.
Table 3.2 Location of Construction Dust Monitoring Station
|
Location
|
Monitoring Station
|
Description
|
|
E-A14a
[1]
|
Block
B of Merit Industrial Centre
|
Rooftop
(13/F)
|
Note:
[1] The air monitoring station proposed in the
EM&A Manual (i.e. Wyler Gardens with ID: E-A14) was not available for
impact dust monitoring, therefore impact monitoring was conducted at E-A14a as
an alternative which was agreed by the ER, IEC and EPD.
Monitoring Methodology
3.1.6 24-hour TSP Monitoring
(a)
The HVS was
installed in the vicinity of the air sensitive receivers. The following criteria were considered in the
installation of the
HVS as far as practicable:-
(i)
A horizontal platform with
appropriate support to secure the sampler against gusty wind was provided.
(ii)
Two samplers should
not be placed less than 2m apart from each others;
(iii)
The distance between the HVS and
any obstacles, such as buildings, was at least twice the height that the
obstacle protrudes above the HVS.
(iv)
A minimum of 2 meters separation
from walls, parapets and penthouse for rooftop sampler.
(v)
A minimum of 2 meters separation
from any supporting structure, measured horizontally is required.
(vi)
No furnace or incinerator flues
nearby.
(vii)
Airflow around the sampler was
unrestricted.
(viii)
The sampler was located more than
20 meters from any dripline.
(ix)
Any wire fence and gate, required
to protect the sampler, did not obstruct the monitoring process.
(x)
Permission was obtained to set up
the samplers and access to the monitoring station.
(xi)
A secured supply of electricity
was obtained to operate the sampler.
(b)
Preparation of
Filter Papers
(i)
Glass fibre filters, G810 were
labelled and sufficient filters that were clean and without pinholes were
selected.
(ii)
All filters were equilibrated in
the conditioning environment for 24 hours before weighing. The conditioning
environment temperature was around 25 °C and not variable by more than ±3 °C;
the relative humidity (RH) was < 50% and not variable by more than ±5%. A
convenient working RH was 40%.
(iii)
All filter papers were prepared
and analysed by ALS Technichem (HK) Pty
Ltd., which is a HOKLAS accredited laboratory and has
comprehensive quality assurance and quality control programmes.
(c)
Field
Monitoring
(i)
The power supply was checked to ensure the HVS works properly.
(ii)
The filter holder and the area
surrounding the filter were cleaned.
(iii)
The filter holder was removed by
loosening the four bolts and a new filter, with stamped number upward, on a
supporting screen was aligned carefully.
(iv)
The filter was properly aligned
on the screen so that the gasket formed an airtight seal on the outer edges of
the filter.
(v)
The swing bolts were fastened to
hold the filter holder down to the frame.
The pressure applied was sufficient to avoid air leakage at the edges.
(vi)
Then the shelter lid was closed
and was secured with the aluminium strip.
(vii)
The HVS was warmed-up for about 5
minutes to establish run-temperature conditions.
(viii)
A new flow rate record sheet was
set into the flow recorder.
(ix)
On site temperature and
atmospheric pressure readings were taken and the flow rate of the HVS was
checked and adjusted at around 1.3 m3/min, and complied with the
range specified in the EM&A Manual (i.e. 0.6-1.7 m3/min).
(x)
The programmable digital timer
was set for a sampling period of 24 hrs, and the starting time, weather
condition and the filter number were recorded.
(xi)
The initial elapsed time was
recorded.
(xii)
At the end of sampling, on site
temperature and atmospheric pressure readings were taken and the final flow
rate of the HVS was checked and recorded.
(xiii)
The final elapsed time was
recorded.
(xiv)
The sampled filter was removed
carefully and folded in half length so that only surfaces with collected
particulate matter were in contact.
(xv)
It was then placed in a clean
envelope and sealed.
(xvi)
All monitoring information was
recorded on a standard data sheet.
(xvii) Filters were then sent to ALS Technichem
(HK) Pty Ltd. for analysis.
(d)
Maintenance and
Calibration
(i)
The HVS and its accessories were maintained in good working condition, such as replacing
motor brushes routinely and checking electrical wiring to ensure a continuous
power supply.
(ii)
HVSs were calibrated using
TE-5025A Calibration Kit upon installation and thereafter at bi-monthly
intervals.
(iii)
Calibration certificate of the TE-5025A Calibration Kit and the HVSs are provided in Appendix E.
3.1.7 1-hour TSP Monitoring
(a)
Measuring Procedures
The measuring procedures of the 1-hour dust
meter are in accordance with the Manufacturer’s Instruction Manual as follows:
(i)
Turn the power on.
(ii)
Close the air collecting opening cover.
(iii)
Push the “TIME SETTING” switch to [BG]
(iv)
Push “START/STOP”
switch to perform background measurement for 6 seconds.
(v)
Turn the knob at SENSI ADJ position to insert
the light scattering plate.
(vi)
Leave the equipment for 1 minute upon “SPAN
CHECK” is indicated in the display.
(vii)
Push “START/STOP” switch to perform automatic
sensitivity adjustment. This measurement takes 1 minute.
(viii)
Pull out the knob and return it to MEASURE
position.
(ix)
Push the “TIME SETTING” switch the time set
in the display to 3 hours.
(x)
Lower down the air collection opening cover.
(xi)
Push “START/STOP” switch to start
measurement.
(b)
Maintenance and Calibration
(i)
The 1-hour TSP meter was
calibrated at 1-year intervals against a continuous particulate TEOM Monitor,
Series 1400ab. Calibration certificates of the Laser Dust Monitors are provided in Appendix E.
Monitoring
Schedule for the Reporting Month
3.1.8
The schedule for environmental monitoring
in April 2018 is provided in Appendix F.
Monitoring Requirements
3.2.1 In accordance with the EM&A Manual, impact noise monitoring should be conducted for
at least once a week during the construction phase of the Project. Table 3.3
summarizes the monitoring parameters, frequency and duration of impact
noise monitoring. The Action and Limit Levels of the noise monitoring is
provided in Appendix D.
Table 3.3 Noise Monitoring Parameters, Frequency and Duration
|
Parameter and Duration
|
Frequency
|
|
30-mins
measurement at each monitoring station between 0700 and 1900 on normal
weekdays. Leq, L10 and L90 would be
recorded.
|
At least once per week
|
Monitoring Equipment
3.2.2 Noise
monitoring was performed using sound level meter at each designated monitoring
station. The sound level meters deployed
comply with the International Electrotechnical Commission Publications (IEC)
651:1979 (Type 1) and 804:1985 (Type 1) specifications. Acoustic calibrator was deployed to check the
sound level meters at a known sound pressure level. Brand and model of the equipment is given in Table
3.4.
Table 3.4 Noise Monitoring
Equipment for Regular Noise Monitoring
Monitoring Locations
3.2.3
The monitoring stations for construction noise monitoring
pertinent to the Project have been identified based on the approved EM&A
Manual for the Project. Locations of the
noise monitoring stations are summarized in Table 3.5 and shown in Figure 3.2.
Table 3.5 Noise Monitoring Stations during Construction Phase
|
Location
|
Monitoring Station
|
Description
|
Measurement
|
|
E-N12a [1]
|
19 Hing Yan Street
|
Rooftop (9/F)
|
Façade
|
|
E-N21a [1]
|
Block B of Merit Industrial Centre
|
Rooftop (13/F)
|
Free field [2]
|
Notes:
[1] The noise monitoring stations proposed in the EM&A Manual
(i.e. Grand Waterfront Tower 3 with ID: E-N12 and Hang Chien Court Block J with
ID: E-N21) were not available for impact noise monitoring, therefore impact
monitoring was conducted at E-N12a and E-N21a as an alternative which was agreed by the ER, IEC and
EPD.
[2] A correction of +3 dB(A)
was made to the free field measurements.
Monitoring Parameters, Frequency and Duration
3.2.4 Table 3.6 summarizes the monitoring parameters,
frequency and duration of impact noise monitoring.
Table
3.6 Noise Monitoring Parameters,
Frequency and Duration
|
Location
|
Parameter and Duration
|
Frequency
|
|
E-N12a and E-N21a
|
30-mins measurement at each monitoring
station between 0700 and 1900 on normal weekdays. Leq, L10
and L90 would be recorded.
|
At least once per week
|
Monitoring Methodology
3.2.5 Monitoring Procedure
(a)
The sound level meter was set on
a tripod at a height of 1.2 m above the ground.
(b)
Façade measurement was made at
E-N12a.
(c)
Free field measurements was made
at monitoring location E-N21a. A correction of +3 dB(A) shall be made to the
free field measurements.
(d)
The battery condition was checked to ensure the correct
functioning of the meter.
(e)
Parameters such as frequency
weighting, the time weighting and the measurement time were set as follows:
(i)
frequency weighting: A
(ii)
time weighting: Fast
(iii)
time measurement: Leq(30-minutes)
during non-restricted hours i.e. 0700 – 1900 on normal weekdays.
(f)
Prior to and after each noise
measurement, the meter was calibrated using the acoustic calibrator for 94
dB(A) at 1000 Hz. If the difference in
the calibration level before and after measurement was more than 1 dB(A), the
measurement would be considered invalid and repeat of noise measurement would
be required after re-calibration or repair of the equipment.
(g)
During the monitoring period, the
Leq, L10 and L90 were recorded. In addition, site conditions and noise
sources were recorded on a standard record sheet.
(h)
Noise measurement was paused
during periods of high intrusive noise (e.g. dog barking, helicopter noise) if
possible. Observations were recorded when intrusive noise was unavoidable.
(i)
Noise monitoring was cancelled in
the presence of fog, rain, wind with a steady speed exceeding 5m/s, or wind
with gusts exceeding 10m/s.
3.2.6 Maintenance and Calibration
(a)
The microphone
head of the sound level meter was cleaned with soft cloth at
regular intervals.
(b)
The meter and
calibrator were sent to the supplier or HOKLAS laboratory to check and
calibrate at yearly intervals.
(c)
Calibration
certificates of the sound level meters and acoustic calibrators are provided
in Appendix E.
Monitoring
Schedule for the Reporting Month
3.2.7
The schedule for environmental monitoring
in April 2018 is provided in Appendix F.
3.3
Landscape and Visual
3.3.1 As per the
EM&A Manuals, the landscape and visual mitigation measures shall be
implemented and site inspections should be undertaken once every two weeks
during the construction period. A summary of the implementation status is presented in Section 6.
4.1.1 The Contractor
has implemented environmental mitigation measures and requirements as stated in
the EIA Reports, the EP and EM&A Manuals. The implementation status of the
environmental mitigation measures during the reporting period is summarized in Appendix C.
5.1.1 The monitoring
results for 24-hour TSP and 1-hour TSP are summarized in Table 5.1 and Table
5.2, respectively. Detailed
air quality monitoring results and daily
extract of meteorological observations are presented in Appendix G.
Table 5.1 Summary of 24-hour
TSP Monitoring Result in the Reporting Period
|
ID
|
Average (mg/m3)
|
Range (mg/m3)
|
Action Level (mg/m3)
|
Limit Level (mg/m3)
|
|
E-A14a
|
76.7
|
46.4 – 101.5
|
197.3
|
260
|
Table 5.2 Summary of 1-hour TSP Monitoring Result in the Reporting
Period
|
ID
|
Average (mg/m3)
|
Range (mg/m3)
|
Action Level (mg/m3)
|
Limit Level (mg/m3)
|
|
E-A14a
|
67.2
|
59.2 – 97.9
|
302.4
|
500
|
5.1.2
No Action and Limit Level exceedance was recorded
for 24-hour TSP monitoring at the monitoring location in
the reporting month.
5.1.3
No Action and Limit Level exceedance was recorded
for 1-hour TSP monitoring at the monitoring location in
the reporting month.
5.1.4
The event and action plan is annexed in
Appendix I.
5.1.5 Major dust
sources during the monitoring included construction dust and nearby traffic
emission.
5.2.1 The monitoring
results for noise are summarized in Table 5.3 and the monitoring data is
provided in Appendix H.
Table 5.3 Summary of Construction Noise Monitoring Results in the
Reporting Period
|
ID
|
Range, dB(A), Leq (30
mins)
|
Limit Level, dB(A), Leq
(30 mins)
|
|
E-N12a
|
59.6 – 64.7
|
75
|
|
E-N21a
|
63.3 – 67.4
|
75
|
5.2.2
No noise complaint was
received in the reporting month; hence, no Action Level exceedance was
recorded.
5.2.3
No Limit Level exceedance of noise was
recorded at the monitoring station in the reporting month.
5.2.4
The event and action plan is annexed in Appendix I.
5.2.5
Major noise sources during the
monitoring included construction noise from the Project site and nearby traffic
noise.
5.3.1
C&D materials and wastes sorting were carried
out on site. Receptacles were available for C&D wastes and general refuse collection.
5.3.2
As advised by the Contractor, 91 m3 of
inert C&D
material was generated and disposed of as public fill in the
reporting month. 34,080 kg general refuse was generated and sent to NENT
Landfill in the reporting month. No metals, paper/cardboard packaging
and plastics were collected by recycle contractor in the reporting month. No
chemical waste
was collected by licensed contractor in the reporting period.
No Type 1 or 2 Marine sediment was disposed at Confined Marine Disposal
Facility to the East of Sha Chau. The waste
flow table is annexed in Appendix K.
5.3.3 The Contractor is advised
to properly maintain on site C&D materials and wastes collection, sorting
and recording system and maximize reuse / recycle of C&D materials and
wastes. The Contractor is reminded to properly maintain the site tidiness and
dispose of the wastes accumulated on site regularly and properly.
5.3.4 The Contractor is reminded
that chemical waste containers should be properly treated and stored
temporarily in designated chemical waste storage area on site in accordance
with the Code of Practise on the Packaging, Labelling and Storage of Chemical
Wastes.
5.4.1
Bi-weekly inspection of the
implementation of landscape and visual mitigation measures was conducted on 4
and 18 April 2018. A summary of the site inspection is
provided in Appendix C. The observations and recommendations made during
the site inspections are presented in Table 6.1.
6.1.1 Site
inspections were carried out on a
weekly basis to monitor the implementation of proper environmental pollution
control and mitigation measures for the Project. A summary of the mitigation
measures implementation schedule is provided in Appendix C.
6.1.2
In the reporting month, 4 site inspections were
carried out on 4, 11, 18 and 25 April 2018. Joint
inspections with the IEC, ER, the Contractor and the ET were conducted on 18
April 2018. No non-compliance was recorded during the site inspection. Details of
observations recorded during the site inspections are presented in Table 6.1.
Table 6.1 Observations and Recommendations of Site Audit
|
Parameters
|
Date
|
Observations and Recommendations
|
Follow-up
|
|
Air Quality
|
4 April 2018
|
· The Contractor
was reminded to enhance the watering for exposed surface at Kai Tak.
|
The item was
rectified by the Contractor on 4 April 2018.
|
|
18 April 2018
|
· The Contractor
was reminded to enhance the watering for exposed surface at Kai Tak.
|
The item was
rectified by the Contractor on 24 April 2018.
|
|
Noise
|
Nil
|
Nil
|
Nil
|
|
Water Quality
|
18 April 2018
|
·
The Contractor was reminded to provide extra
protection for the gully at Ma Tau Kok Public Pier.
|
The item was
rectified by the Contractor on 24 April 2018.
|
|
Waste/ Chemical Management
|
Nil
|
Nil
|
Nil
|
|
Landscape
& Visual
|
Nil
|
Nil
|
Nil
|
|
Permits/
Licenses
|
Nil
|
Nil
|
Nil
|
6.1.3
All follow-up actions requested by Contractor's ET and
IEC during the site inspection were undertaken as reported by the Contractor
and confirmed in the following
weekly site inspection conducted during the reporting period.
6.2.1
All 24-hour TSP result was below the
Action and Limit Levels at all monitoring locations in the reporting month.
6.2.2
All 1-hour TSP result was below the Action
and Limit Levels at all monitoring locations in the reporting month.
6.2.3 No noise complaint was received
in the reporting month; hence, no Action
Level exceedance was recorded.
6.2.4
No Limit Level exceedance for noise was
recorded at all monitoring stations in the reporting month.
6.3.1
No environmental non-compliance was
recorded in the reporting month.
6.4.1
No environmental related complaint was received in the
reporting month. Cumulative statistics on environmental
complaints is provided in Appendix J.
6.5.1 No
environmental related prosecution or notification of summons was received in
the reporting month. Cumulative statistics on notification of summons and
successful prosecutions is provided in Appendix J.
7.1.1
The major construction works between May 2018 and July 2018
will be:
|
Locations
|
Site
Activities
|
|
Kai Tak
|
·
Pipe piling
·
Sheet piling
·
Hoarding erection
·
U-channel and drainage works
·
Construction of site offices
|
|
Ma Tau Kok
|
·
Site investigation
·
Site clearance
·
Tree felling
·
Temporary Traffic Management
implementation
·
Alternation and temporary reinstatement
of road pavements for Temporary Traffic Arranagement stages
·
Installation of monitoring instrument
·
Hoarding erection
·
Existing bus shelter removal
·
Provision of temporary bus shelters
·
Demolition of existing vehicular ramp and
booth structure
|
7.2.1
Potential environmental impacts arising
from the above construction activities are mainly associated with construction dust, construction noise, and
waste management.
7.3.1 The
tentative schedule for environmental monitoring in May 2018 is
provided in Appendix F.
8.1.1
24-hour TSP and noise monitoring were
carried out in the reporting month.
8.1.2
All 24-hour TSP monitoring results
complied with the Action / Limit Level at in
the reporting month.
8.1.3
All 1-hour TSP result was below the Action
and Limit Levels at all monitoring locations in the reporting month.
8.1.4
No noise complaint was received in the reporting month. Hence, no
Action
Level exceedance was recorded.
8.1.5
No Limit Level exceedance for noise was recorded
at all monitoring
stations in the reporting month.
8.1.6 4 nos. of environmental site inspections were carried out in April 2018.
Recommendations on remedial actions were given to the Contractor for the
deficiencies identified during the site audit.
8.1.7
Referring to the Contractor's information, no environmental related
complaint, notification of summons and successful prosecution was received in
the reporting month.
8.2.1
According to the environmental site inspections
performed in the reporting month, the following recommendations were provided:-
Air Quality Impact
· The Contractor was reminded to enhance the watering
for exposed surface at Kai Tak.
Construction Noise Impact
· No specific observation was identified in the
reporting month.
Water Quality Impact
· The Contractor was reminded to provide extra
protection for the gully at Ma Tau Kok Public Pier.
Chemical and Waste Management
· No specific observation was identified in the
reporting month.
Landscape & Visual Impact
· No specific observation was identified in the
reporting month.
Permits/licenses
· No specific observation was identified in the
reporting month.
_files/image006.jpg)
_files/image008.gif)
_files/image010.gif)
